CLEANER 3# Ink Remover

Product Highlights

Product Features

As time goes by, the ink and solder mask ink used in PCB screen printing accumulate more and more on the screen frame. This ink cannot be removed by traditional solvents, such as EGBE (ethylene glycol monobutyl ether), also known as 2-Butoxyethanol or acetone; it cannot be removed by mechanical methods, such as scraping or rubbing.

CLEANER3# screen frame cleaner is a new type of special solvent for cleaning screen frames developed by our company. It can be used to clean various types of metal screen frames without damaging the metal on the surface of the screen frame.

Direct immersion and short immersion time saves time and effort, has little odor, is easy to clean, does not require heating, and reduces energy waste.

Physical and Chemical Parameters  CLEANER 3#

Instructions for use

Clean the tank and add 100% CLEANER3# stock solution, temperature: room temperature.

Directly put the screen frame in and soak for 10-30 minutes (adjust according to the thickness of ink accumulation on the surface of the screen frame).

After wiping with a rag or brush, rinse with water.

Addition: As the number of cleanings increases, when the working tank liquid level decreases, the liquid level must be replenished.

Slot replacement frequency: When the screen cleaning time is extended to 2~3 hours or when there is too much ink deposition, the slot must be replaced. Generally, 1 slot can clean 1000-3000 screen frames.

Exhaust: Required, and the operating environment is open and ventilated.

Cleaning Tank Material Requirements

Stainless steel 316 or 304

Teflon

Titanium

Special PP material

Packing Specifications

20KG

Storage and Transportation Requirements

Transport as non-hazardous chemicals and non-corrosive chemicals.

Store at room temperature.

Keep sealed and away from direct sunlight and high heat.

Warranty period for sealed state is 12 months.
